Outlined Collapsible for Svelte

A thick-outlined System Information box that opens to version 2.1.0, status Active, and a last update.

UI library: Ark UI

System Information sits in a thick outline, with a chevron. It opens to Version 2.1.0, Status Active, and Last Updated 2 hours ago.

Use it on an about or support panel. If these facts should always show, put them in a Card. In Svelte, Ark UI does not remember that the outline was open.

Preview

Preview width

Installation

MCP · Pro
Make your AI a shadcn expert
Your agent installs components, builds pages and restyles your app from one prompt, in Claude Code, Cursor or VS Code.
Part of Pro

Anatomy

Collapsible anatomy: root, trigger, indicator, content

Usage

<Collapsible class="w-full max-w-lg rounded-md border-2"><CollapsibleTrigger class="group flex w-full items-center justify-between p-4 font-medium">System Information<ChevronDownIcon aria-hidden="true" class="size-4 transition-transform duration-200 group-aria-expanded:rotate-180" /></CollapsibleTrigger><CollapsibleContent class="border-t-2"><div class="flex flex-col gap-2 p-4 text-muted-foreground text-sm">{#each info as item (item.label)}<div><span class="font-medium">{item.label}:</span> {item.value}</div>{/each}</div></CollapsibleContent></Collapsible>

FAQ

Where does the thick border sit?

Collapsible has rounded-md border-2, and CollapsibleContent has border-t-2, so the divider matches the outline's weight.

How are Version, Status, and Last Updated written?

They come from the info list at the top of the file, in a flex flex-col gap-2 column. Each row is a bold label with a colon, then its value in the muted color.

Does the chevron rotate?

Yes. The trigger has the group class and sets aria-expanded while open, so group-aria-expanded:rotate-180 on ChevronDownIcon turns it, eased by transition-transform duration-200.

How do I start System Information open?

Set defaultOpen on Collapsible.

It starts closed.

How do I open it from the keyboard?

Tab reaches the trigger, a button named System Information, and Space or Enter shows or hides the rows.

How do I turn the height animation off?

Set disableAnimation on CollapsibleContent, and the rows appear at once. Reduced motion settings already turn it off.

API Reference

Collapsible

No extra props in this demo. The rest is on the Collapsible page.
