A simple area chart for React

One smooth desktop curve across six months, with the area under it filled. Horizontal grid lines and a line marker in the tooltip.

One smooth desktop curve across six months, with the area under it filled. Grid lines are horizontal. The tooltip uses a line marker.

Use an area when the volume under the trend matters, not just the line. A line is lighter when the fill adds nothing. A Table is better for the raw months. In React, Base UI does not fill under the curve. You pass the series and its color.

Preview

Preview width

Installation

Sign in to get your install command
Free with an account. It carries your token, so the CLI installs everything in one go.
GoogleGitHub
Use email insteadNo credit card

Anatomy

Chart anatomy: container, grid, axis, bar, tooltip, legend

Usage

<div className="w-full max-w-xl rounded-md border bg-background p-4">
  <ChartContainer config={chartConfig}>
    <AreaChart
      accessibilityLayer
      data={chartData}
      margin={{
        left: 12,
        right: 12,
      }}
    >
      <CartesianGrid vertical={false} />
      <XAxis
        axisLine={false}
        dataKey="month"
        tickFormatter={formatMonth}
        tickLine={false}
        tickMargin={8}
      />
      <ChartTooltip
        content={<ChartTooltipContent indicator="line" />}
        cursor={false}
      />
      <Area
        dataKey="desktop"
        fill="var(--color-desktop)"
        fillOpacity={0.4}
        stroke="var(--color-desktop)"
        type="natural"
      />
    </AreaChart>
  </ChartContainer>
</div>

FAQ

How do I get the smooth curve?

Area sets type="natural", dataKey="desktop", fill="var(--color-desktop)", and stroke="var(--color-desktop)". fillOpacity={0.4} fades the area under that stroke. The color comes from config, where desktop is var(--chart-1) and the label is Desktop.

Why do the ticks say Jan?

XAxis uses dataKey="month" and tickFormatter={formatMonth}. formatMonth returns value.slice(0, 3), so January becomes Jan. axisLine and tickLine are false, and tickMargin is 8.

Why are the grid lines only horizontal?

CartesianGrid sets vertical={false}, so only the horizontal lines render. AreaChart sets accessibilityLayer and a margin of left: 12 and right: 12.

What does the tooltip show?

ChartTooltipContent sets indicator="line", a short bar in the series color. With one series, the month sits in that row with the Desktop label and the value. cursor={false} on ChartTooltip turns the hover cursor off.

Can I move across the points with the keyboard?

Yes. accessibilityLayer on AreaChart lets the plotted points take focus. The month tick and the Desktop label in config are the names for each point.

How tall is this chart?

ChartContainer has no size class, so it keeps the default 16:9 box. The frame around it is w-full max-w-xl. Set a height, or aspect-auto with a fixed height, on ChartContainer when you need a different box.

API Reference

Chart

Sets config={chartConfig} and indicator="line". The rest is on the Chart page.
